16*FE+2*1000Base-S/LX Ethernet Switch

    FC-SW16 is Ethernet IEEE802.3 media transceiver to achieve media conversion or extending network transmission distance between two kinds of media, which are 16*10/100Base-T UTP and 2*1000Base-S/LX. It mainly used for fiber network far distance (20/40/60/80/100km) transmission, supports 10/100/1000M or 10M,100M,1000M transmission rate. Fiber port and UTP can work through 100M or 1000M rate.

◆Ethernet UTP/STP interface automatically adapt to 10/100Mbps environment, upgrade network easily;
◆Device provides 16*FE UTP/STP interface, and 2*1000BASE-S/LX interface with SFP fiber module.
◆Support full-duplex and half duplex network communication, with auto-negotiation capability;
◆The max package length up to 1632 Bytes, which can match with the switch product complied with IEEE802.10 protocol
◆Support UTP cross connection switch optional, convenient for system debugging and setup
◆Device provides Console port, supports Terminal control device
◆Ethernet port priority setting
◆AC 220V, DC-48V, DC24V can be optional, and DC-48V/DC24V power has polarity automatic detection function, you can install the device without differentiation between positive and negative polarity.

Ethernet UTP Interface
Interface rate: 10/100 M, half/full duplex auto-negotiation
Interface Standard: Compatible with IEEE 802.3, IEEE 802.1Q (VLAN)
MAC Address Capability: 4096
Connector: RJ45, support Auto-MDIX
Optical Ethernet interface
Wave Length: 1310nm, 1550nm
Interface rate: 1000 M, half/full duplex
Interface Standard: Compatible with IEEE 802.3, IEEE 802.1Q (VLAN)
MAC Address Capability: 4096
Connector: FC/SC
    Fiber Transmission Distance is limited by optical circuit loss and additional loss as a result of connectors, fittings and patch panel.Transmission distance may also be limited by fiber optic bandwidth.
Working environment
Working temperature: -10°C ~ 50°C
Working Humidity: 5%~95 % (no condensation)
Storage temperature: -40°C ~ 80°C
Storage Humidity: 5%~95 % (no condensation)
